The 4GB Raspberry Pi 4 Model B is the latest product in the popular Raspberry Pi range of computers.
It offers ground-breaking increases in processor speed, multimedia performance, memory, and connectivity compared to the previous generation Raspberry Pi 3 Model B+, while retaining backwards compatibility and similar power consumption.
For the end user, Raspberry Pi 4 Model B provides desktop performance comparable to entry-level x86 PC systems.
The product's key features include a high-performance 64-bit quad-core processor, dual-display support at resolutions up to 4K via a pair of micro-HDMI ports, hardware video decode at up to 4Kp60, 4GB of RAM, dual-band 2.4/5.0GHz wireless LAN, Bluetooth 5.0, Gigabit Ethernet, USB 3.0, and PoE capability (via a separate PoE HAT add-on).
The dual-band wireless LAN and Bluetooth have modular compliance certification, allowing the board to be designed into end products with significantly reduced compliance testing, improving both cost and time to market.
- Memory (RAM): 4GB
- 2.4GHz and 5.0GHz IEEE 802.11b/g/n/ac wireless LAN
- Bluetooth 5.0
- BLE True Gigabit Ethernet
- 2x Micro HDMI ports supporting up to 4K 60Hz video resolution
- Applications include embedded design & development, IoT
- PCB size 85 x 56mm
